HD6012-RW 2MP IR In-Ceiling IP Dome Camera with WDR
- SKU:
- HD6012-RW
- Resolution:
- 2MP (1080p)
- Number of Video Streams:
- 2 (Primary high resolution stream for single camera view, secondary low resolution stream for multiple camera view)
- Frames Per Second:
- 30 IPS @ 1080P
- Wide Dynamic Range:
- Spectrum Vision True WDR
- Focal Length:
- 4 mm Fixed
- Field of View:
- 86°
- Lens Adjustment:
- 2-Axis
- Iris Control:
- F2 Fixed
- Backlight Compensation:
- Yes
- Auto Gain Control:
- Yes
- Minimum Illumination:
- Color : 2.4 Lux @ F2.0 B/W : 0.5 Lux @ F2.0
- Day / Night:
- True Day / Night
- Max IR Range:
- 50 feet (15 m)
- Optimal IR Range:
- Up to 30 feet (9m) from camera
- Effective Range @ 60 / 40 / 20 PPF <sup>1</sup>:
- 24' / 36' / 72'
- Auto White Balance Range:
- 2700K ~ 8000K
- Privacy Masking:
- Yes
- Compression:
- H.264 / MPEG 4/ MJPEG
- MicroSD Backup Slot:
- microSD Slot
(up to 32gb capacity)
- IP Rating:
- N/A (Indoor Only)
- Tamper/Vandal Resistant:
- No
- Cooling:
- Fan2
- Heater:
- No
- ONVIF Compliance:
- Profile S
- Input Voltage:
- PoE Only IEEE 802.3af Power over Ethernet 48vDC
- Power Consumption:
- 5 W (Max)
- Operating Temperature:
- 14°F (-10°C)~122°F (50°C)
- Cold Start Temperature:
- 14°F
- Dimensions:
- 3.56" x 4.5"
(90.4 mm x 114.5 mm)
- Weight:
- .5 lbs (221 g)
- Item Includes:
- 100' Cat5e camera cable, Mounting hardware
- Optional Mounts:
- N/A
- Notes: <sup>1</sup>:
- For more information about effective range and PPF, see our DIY Guide How Far Can I See with My Cameras?
- <sup>2</sup>:
- In-ceiling cameras require fans for cooling. Not recommended for use in areas that are sensitive to noise.
Note: This camera is only Plug and Play compatible with ProConnect Series NVRs. Can be added manually via ONVIF to Performance Series recorders. See FAQs for steps. For previous generations of recorders, we strongly recommend the HD810 Dome Camera.
Retail Rock Star
The HD6012 is a specialty dome camera designed to be installed in drop ceiling tiles. This leaves a just a small profile dome protruding from the ceiling. This is perfect for retail and office environments where you want a camera for deterrence, but that doesn't stand out. Spectrum Vision True WDR provides excellent performance in locations with large windows or glass doors. It also has IR night vision for seeing close proximity (30 feet) activity in complete darkness (0 lux). This camera blends in well with its surroundings and is aesthetically pleasing to the eye.
In-ceiling cameras require fans for cooling. Not recommended for use in areas that are sensitive to noise.
Spectrum Vision WDR
Spectrum Vision WDR (wide dynamic range) compensates for uneven light conditions caused by shadows, obstructions, back light and inconsistent lighting. Cameras with Digital WDR may show some improvement for these conditions but do not achieve optimum results. Spectrum Vision WDR from AvertX uses double exposure technology that includes both optical and digital image processing. The result is superior video quality compared to Digital WDR.
Megapixel Cameras
View video and images with more clarity and detail with megapixel cameras from AvertX. This image depicts the video image difference between various video streaming technologies. Analog systems typically provide top resolution of 960x480 pixels, which is significantly smaller than the image provided by high definition megapixel cameras. High definition is 1920x1080 pixels or higher, similar to a new 1080p HD television. AvertX offers IP cameras from 2MP to 4MP.
IR LEDs for Night Vision
Capture images covertly without bright lights disturbing your sleep or having to leave all the lights on in your business. AvertX Night Vision HD cameras use LED illuminators to produce infrared light that is not visible to the human eye, allowing your surveillance system to see intruders even when they can’t see themselves.
*IR Night Vision is black and white and range can be affected by a number of factors. Obstacles and reflective surfaces may limit performance depending on the installation location.
The Professional Difference
AvertX systems use professional grade hardware that is designed for any location where video surveillance would provide peace of mind, including your home, business, or school. The rock solid hardware will provide peak performance and reliable operation for years to come and crystal clear 1080P IP video. We strive to offer the most secure products available to ensure you have the protection you need. You can count on having clear HD video if an incident occurs. AvertX products carry a professional warranty of 2 years.
Privacy Masks
Create a privacy mask on your AvertX camera to block recording and viewing of a designated area within the field of view of the camera. This feature allows you to block sensitive areas to protect privacy while still recording what is happening around it. A privacy mask gives you greater flexibility to place your cameras where they capture what you want, while maintaining the privacy or confidentially of assets, secure entry devices, documents, license plates, windows or areas where privacy is important.
Pain Free Installation
AvertX has designed its system with integral features to simplify installation. An integrated PoE switch means you only need to run single cable your cameras. At startup, the ProConnect NVR recognizes your cameras and starts recording. The key to a successful installation is planning. Please visit our DIY Corner for resources to choose the appropriate system for your home or business and tips and tricks for installing and getting the most out of your system. If you have any questions about your installation, call the AvertX PRO Team!
Camera includes 100’ CAT5e Ethernet cable for camera connections
Your Video Safe And Secure
AvertX cameras allow you to install, and record directly to, a standard microSD card internally as an added layer of backup. Simply install your microSD card in the slot inside the camera and, even if your recorder is stolen, you can pull video directly from the camera. To further safeguard your video, AvertX HDIP recorders exclusively use large capacity, A/V rated commercial storage drives designed for 24/7 continuous recording, just like the pros do.
* microSD card not included
ONVIF COMPLIANT
AvertX HDIP cameras are ONVIF Profile S compliant and compatible with other ONVIF compliant recorders. Plug and Play automatic configuration is only available with AvertX HDIP recorders.
Specifications
- SKU:
- HD6012-RW
- Resolution:
- 2MP (1080p)
- Number of Video Streams:
- 2 (Primary high resolution stream for single camera view, secondary low resolution stream for multiple camera view)
- Frames Per Second:
- 30 IPS @ 1080P
- Wide Dynamic Range:
- Spectrum Vision True WDR
- Focal Length:
- 4 mm Fixed
- Field of View:
- 86°
- Lens Adjustment:
- 2-Axis
- Iris Control:
- F2 Fixed
- Backlight Compensation:
- Yes
- Auto Gain Control:
- Yes
- Minimum Illumination:
- Color : 2.4 Lux @ F2.0 B/W : 0.5 Lux @ F2.0
- Day / Night:
- True Day / Night
- Max IR Range:
- 50 feet (15 m)
- Optimal IR Range:
- Up to 30 feet (9m) from camera
- Effective Range @ 60 / 40 / 20 PPF <sup>1</sup>:
- 24' / 36' / 72'
- Auto White Balance Range:
- 2700K ~ 8000K
- Privacy Masking:
- Yes
- Compression:
- H.264 / MPEG 4/ MJPEG
- MicroSD Backup Slot:
- microSD Slot
(up to 32gb capacity)
- IP Rating:
- N/A (Indoor Only)
- Tamper/Vandal Resistant:
- No
- Cooling:
- Fan2
- Heater:
- No
- ONVIF Compliance:
- Profile S
- Input Voltage:
- PoE Only IEEE 802.3af Power over Ethernet 48vDC
- Power Consumption:
- 5 W (Max)
- Operating Temperature:
- 14°F (-10°C)~122°F (50°C)
- Cold Start Temperature:
- 14°F
- Dimensions:
- 3.56" x 4.5"
(90.4 mm x 114.5 mm)
- Weight:
- .5 lbs (221 g)
- Item Includes:
- 100' Cat5e camera cable, Mounting hardware
- Optional Mounts:
- N/A
- Notes: <sup>1</sup>:
- For more information about effective range and PPF, see our DIY Guide How Far Can I See with My Cameras?
- <sup>2</sup>:
- In-ceiling cameras require fans for cooling. Not recommended for use in areas that are sensitive to noise.
Documents and Downloads
Compatability
Note:
This camera is intended for Plug-n-Play use with AvertX’s current generation of ProConnect brand recorders. Use with other manufacturer’s recorders, and prior generation AvertX recorders, is not recommended without first contacting AvertX Pro Support. Additional advanced configuration and limitations such as continuous recording only may apply. See FAQs for steps. For previous generations of recorders, we strongly recommend the HD810 Dome Camera.
